5. A measured view from a window in Brooklyn

Yesterday’s post talked about using your pencil to analyze your view. Your pencil or pen is great both for measuring the proportions of shapes as well as spotting the location of things you see.

Here is a quick sketch that I did last year from our hotel room window in Brooklyn, NY. I loved the wide view that went all the way from the old Brooklyn City Hall to a peekaboo view of the Brooklyn Bridge on the far right, and I wanted to capture it all in my sketch!

How to do that? I used my pencil to measure. The first thing I drew was my eye level line (aka horizon line–you can really see the consistent, flat horizon in the distance between the buildings), as that line functions as a sort of datum line throughout the sketch (plus, all the vanishing points for the buildings will be somewhere on that line!) The ELL is so important! I had to think carefully about how high it should be on the page, and decided if I wanted to get the tops and bottoms of most of the buildings, it would need to be slightly over halfway up the page.

Next I used my pencil to spot locate the edges of major buildings in my view. I figured out that I could divide the view into 4 fairly equal segments that aligned with the edges of some of the prominent buildings. Next I transferred that information to my paper by making tick marks along my eye level line, dividing it into four equal segments for where each of these building edges would appear. (I must have started over 10 times to make sure everything would fit on my page. It’s no big deal to erase these light lines at the beginning of a sketch.) Once the tick marks were in my sketch, I could start to draw in the shapes of the buildings.

Then the big shapes were broken into smaller shapes as I drew floor lines in perspective and refined the “stacked boxes” of the buildings. Detail was added at the end using dark pencil or paint. Note that I didn’t draw in every window, I only suggest the windows in places (near the tops of buildings or the ground), and let them fade out to suggest they continue.

And voilá, a wide angle sketch of my wide angle view!
